特性與優點

採用DSP及IGBT等先進控制技術及開關組件
採用高速DSP處理器的先進冗餘幷機技術,無須外置並聯櫃
裝配無須任何調整,無環流電流
使用複數CPU及軟硬件同時兼容設計
超寬輸入電壓
即插即用模塊化設計和三相獨立逆變器設計
超寬輸入電壓及輸入輸出超隔離配備
三相輸入中點浮接,脫落保護
無市電下冷啓動功能
效率優化功能
人性化的操控設計
智能監控及散熱風扇轉速控制
合理的風道分離設計
多功能的周邊配件
資料記錄能力

PHASE 3-Phase Input / 3-Phase Output
kVA 20 30 40 50 60
DC INPUT
Input Voltage 110/220/348Vdc
INVERTER
Output Voltage 220V / 380V / 460V, 208VY / 380VY / 400VY / 415VY, ± 1 %
Wave Form Sine wave
Output Power Factor 0.8
Frequency Lock Range 50 / 60 Hz ± 3Hz
Output Frequency
(Free Running)
50 / 60 Hz ± 0.1 Hz
Phase Shift Under 100%
Unbalance Load
< 0.5
THD (Linear Load) < 3 %
Overload <110% Continuous
110~125% 15 minutes
125~150% 10 minutes
≧ 150% 1 minute
Efficiency (100% Load) 93% 93.5% 93.5% 94%
STATIC SWITCH
Voltage Range 173-277 VAC (L-N)
Mains Inverter 0 ms
OVERALL CHARACTERISTICS
Overall Efficiency 91% 91.5% 92% 92%
Audible Noise(At 1M) < 65 dBA
Temperature 0 ~ 40゚C ( 32 ~ 104゚F )
Humidity 0% - 90% (non-condensing)
Altitude < 1500M above sea level
EN50091-1,-2 Yes
Short Circuit Protection Yes
Lightning / EMC Filter MOV / Input&Output (FCC CLASS A)
Galvanic Isolation Input&Output true galvanic isolation
LED,LCD,Buzzer Yes
Remote Control /
Communication Interface
Monitoring 1~99 UPS simultaneously / Dry contact, RS232, RS485
✽ Different specifications required are available
✽ All specifications mentioned above are subject to change without prior notice
PHASE 3-Phase Input / 3-Phase Output
kVA 80 100 120 160
DC INPUT
Input Voltage 110/220/348Vdc
INVERTER
Output Voltage 220V / 380V / 460V, 208VY / 380VY / 400VY / 415VY, ± 1 %
Wave Form Sine wave
Output Power Factor 0.8
Frequency Lock Range 50 / 60 Hz ± 3Hz
Output Frequency
(Free Running)
50 / 60 Hz ± 0.1 Hz
Phase Shift Under 100%
Unbalance Load
< 0.5
THD (Linear Load) < 3 %
Overload <110% Continuous
110~124% 15 minutes
125~149% 10 minutes
≧ 150% 1 minute
Efficiency (100% Load) 94.5% 95%
STATIC SWITCH
Voltage Range 173-277 VAC (L-N)
Mains Inverter 0 ms
OVERALL CHARACTERISTICS
Overall Efficiency 92.5% 93%
Audible Noise(At 1M) < 67 dBA
Temperature 0 ~ 40゚C ( 32 ~ 104゚F )
Humidity 0% - 90% (non-condensing)
Altitude < 1500M above sea level
EN50091-1,-2 Yes
Short Circuit Protection Yes
Lightning / EMC Filter MOV / Input&Output (FCC CLASS A)
Galvanic Isolation Input&Output true galvanic isolation
LED,LCD,Buzzer Yes
Remote Control /
Communication Interface
Monitoring 1~99 UPS simultaneously / Dry contact, RS232, RS485
✽ Different specifications required are available
✽ All specifications mentioned above are subject to change without prior notice
PHASE 3-Phase Input / 1-Phase Output
kVA 20 30 40 50
DC INPUT
Input Voltage 110/220/348Vdc
INVERTER
Output Voltage 220/230/240Vac, 1Φ2ωor3ω
Wave Form Sine wave
Output Power Factor 0.8
Frequency Lock Range 50 / 60 Hz ± 3Hz
Output Frequency
(Free Running)
50 / 60 Hz ± 0.1 Hz
Phase Shift Under 100%
Unbalance Load
< 0.5°
THD (Linear Load) < 3 %
Overload <110% Continuous
110~124% 15 minutes
125~149% 10 minutes
≧150% 1 minute
Efficiency (100% Load) 93% 93.5% 93.5%
STATIC SWITCH
Voltage Range 173-277 VAC (L-N)
Mains ←→ Inverter 0 ms
OVERALL CHARACTERISTICS
Overall Efficiency 91% 91.5% 92%
Audible Noise (At 1M) < 65 dBA
Temperature 0 ~ 40゚C ( 32 ~ 104゚F )
Humidity 0% - 90% (non–condensing)
Altitude < 1500M above sea level
EN50091-1,-2 Yes
Short Circuit Protection Yes
Lightning / EMC Filter MOV / Input&Output (FCC CLASS A)
Galvanic Isolation Input&Output true galvanic isolation
LED,LCD,Buzzer Yes
Remote Control /
Communication Interface
Monitoring 1~99 UPS simultaneously / Dry contact, RS232, RS485
✽ Different specifications required are available
✽ All specifications mentioned above are subject to change without prior notice
